Dimensions Guide
Solid
Hollowed
| Diameter |
|---|
| 1" |
| 2" |
| 3" |
| 4" |
| 5" |
| 6" |
| 7" |
| 8" |
Horizontal Continuous Casting
Horizontal Continuous Casting
BC6
NAME
Bronze Continuous Casting Class 6
DIMENSION
CHEMICAL COMPOSITION
Cu 83.0-87.0%
Zn 4.0-6.0%
Sn 4.0-6.0%
Pb 4.0-6.0%
Fe max 0.3%
Ni max 1.0%
Al max 0.01%
GENERAL CHARACTERISTIC
Good pressure resistance, abrasion resistance, and machinability
MECHANICAL PROPERTIES
Tensile: min 245 N/mm2
Elongation: min 15%
Hardness: Min 60 HB
Elongation: min 15%
Hardness: Min 60 HB
APPLICATION
Bearing. Valve sheet ring, water supply parts, general machine parts
We can custom manufacture according to your specific requirements.
